Handheld. Built for the Water.
The APC 60 ED is no ordinary spotting scope – it’s the first of its kind: a fully handheld, image-stabilized scope that delivers remarkably steady images even at high magnifications, thanks to its integrated KDGS-TTK gimbal system. For serious digiscopers – especially on the water – it opens up possibilities that simply aren’t achievable with conventional tripod setups.
Where the APC 60 ED truly shines
Boat trips along the Río Tarcoles, lagoon tours in Barra Colorado, mangrove channels along the Río Sierpe – wherever vibrations, swell, and the lack of a stable footing cause traditional scopes to fail, the APC 60 ED holds its ground. At its core is an active stabilization system: the KDGS-TTK gimbal continuously analyzes and corrects movement in real time. The result is sharp, detailed images and footage – even when the ground beneath you is shifting.
Field experience from multiple trips in Costa Rica confirms: even without a tripod, compelling shots are achievable with the APC 60 ED when the scope is supported on a railing, beanbag, or other improvised rest. For maximum digiscoping results, our tests showed the Ardea CF tripod combined with the Manfrotto MVH500AH fluid head to be the ideal setup.
What sets the APC 60 ED apart
Active Image Stabilization The KDGS-TTK system compensates for vibrations in real time – with a correction angle of up to 2°. The result: tripod-like image stability from the hand or from a boat.
Compact and Travel-Ready 287 mm long, 1,350 g lightweight, waterproof to IPX7 – the APC 60 ED fits in any backpack and handles tropical downpours without complaint.
Modular Eyepiece System The included 17–35x wide-angle eyepiece is compatible with the KSP 80 HD. Anyone who already owns a Kite scope saves the cost of a second eyepiece.
Long Battery Life Up to 36 hours of stabilized use per charge, conveniently recharged via USB-C – ideal for multi-day expeditions far from any power outlet.
ED Optics with High Light Transmission The 58 mm objective with 90% light transmission and ED glass delivers high-contrast, color-accurate, and detail-rich images – even at dusk or under overcast skies.
An honest note on digiscoping
The APC 60 ED allows handheld use – but anyone looking to photograph or film with it needs more than free hands. Positioning a smartphone adapter, operating the camera app, fine-tuning focus, and keeping the scope steady simultaneously: that requires a well-thought-out setup. Our recommendation remains the Ardea CF tripod with the Manfrotto MVH500AH – a combination proven to be reliable and quiet to operate in the field.
Technical Specifications
| Specification | Value |
|---|---|
| Magnification | 17–35x |
| Objective diameter | 58 mm |
| ED optics | Yes |
| Exit pupil | 3.5–1.7 mm |
| Minimum focus distance | 4.2 m |
| Field of view (m/1000m) | 60–41 |
| Field of view (degrees) | 3.4–2.3 |
| Apparent field of view | 58.4–82.2° |
| Eye relief | 18–17 mm |
| Length | 287 mm |
| Dimensions (H × W) | 89 × 69 mm |
| Weight | 1,350 g |
| Twilight factor | 31–45 |
| Light transmission | 90% |
| Waterproofing | IPX7 |
| Gas filled | Yes |
| Operating temperature | −20°C to +45°C |
| Stabilization correction | 2° |
| Battery life | 36 hours |
| Battery type | Li-Ion, integrated |
| Charging | USB-C |
| Tripod thread | Yes |
| Filter thread | M60×0.75 |
| Optics warranty | 30 years |
| Electronics warranty | 5 years |
| SKU | K280307 |
Dealer enquiries warmly welcome – feel free to get in touch directly.
